Occupancy grids and voxel maps stores where space is free, occupied, or unknown. This representation is humble, but it is one of the most actionable maps for navigation, inspection, drone flight, and collision checking.
Problem First: Why This Representation Exists
For occupancy and voxel maps, track resolution, decay, inflation, unknown-space policy, and update latency. The robot evidence is not map beauty; it is whether the planner used the map to avoid collision or request exploration.
For occupancy and voxel maps, track resolution, decay, inflation, unknown-space policy, and update latency. The robot evidence is not map beauty; it is whether the planner used the map to avoid collision or request exploration. Treat the representation as a typed state estimate, not as a visualization.
For Occupancy grids and voxel maps, the representation is embodied only when it changes an admissible action, safety margin, exploration request, or recovery path.
Figure 28.4.1 should be read as the Occupancy grids and voxel maps handoff diagram: sensor evidence, geometric representation, uncertainty, latency, and action consumer are separate failure points.
Mathematical Core
Occupancy mapping usually updates log odds so repeated evidence accumulates without probabilities saturating too quickly.
$\ell_t(m_i)=\ell_{t-1}(m_i)+\log\frac{P(m_i\mid z_t)}{1-P(m_i\mid z_t)}-\ell_0$
The log-odds value $\ell_t$ increases for occupied evidence and decreases for free-space evidence. Unknown is not free; it is a separate epistemic state that planners should treat according to task risk.
- Cast a ray from the sensor through the measured endpoint.
- Decrease occupancy log odds for traversed cells before the hit.
- Increase occupancy log odds for the endpoint cell.
- Inflate occupied cells by robot radius before planning.
| Design Choice | Use When | Control Risk |
|---|---|---|
| 2D grid | Ground robots on mostly flat floors | Cannot represent overhangs or drone clearance. |
| 3D voxel map | Drones, manipulation, cluttered interiors | Memory and update cost grow quickly. |
| TSDF or ESDF | Surface reconstruction and planning distances | Truncation and integration choices affect thin objects. |
Worked Miniature
Code Fragment 28.4.1 performs a tiny log-odds update for free and occupied cells along one range ray. The same idea powers larger occupancy and voxel maps.
# Apply one log-odds occupancy update along a range ray.
# Free cells decrease, the hit cell increases, and unknown cells remain unchanged.
import numpy as np
log_odds = np.zeros(6)
free_cells = [0, 1, 2, 3]
hit_cell = 4
log_odds[free_cells] += -0.4
log_odds[hit_cell] += 0.9
prob = 1 / (1 + np.exp(-log_odds))
print(np.round(prob, 2))The expected output shows cells 1 through 4 moving toward free space, cell 5 accumulating occupied evidence, and cell 6 staying unknown at 0.50. A planner should therefore interpret this vector as "one likely obstacle, several cleared cells, and one unobserved cell," not as a complete map.
OctoMap, OpenVDB-style voxel structures, ROS 2 cost maps, and simulator occupancy layers provide maintained implementations. The library route handles memory and ray integration, while the builder defines sensor models, inflation, and unknown-space policy.
Treating unknown cells as free is a planning choice, not a fact. It may be acceptable for exploration and unacceptable for high-speed navigation or human-adjacent robots.
A warehouse drone should inflate occupied voxels by its body radius and reserve an additional margin for localization uncertainty before accepting a path through shelving.
For Occupancy grids and voxel maps, the perception result must answer what action changed, what uncertainty changed, and what log would reproduce the decision. Otherwise the output is still visualization, not embodied evidence.
Debugging And Evaluation
For Occupancy grids and voxel maps, evaluate the representation inside the consuming action loop with calibration, frame transform, representation version, latency, selected action, and failure label.
For Occupancy grids and voxel maps, perturb exactly one geometric assumption, such as depth dropout, scale, occlusion, pose drift, motion, or calibration, then record the action change.
Occupancy maps are being combined with neural scene representations and learned priors. The important research tension is between dense, expressive memory and the hard real-time guarantees needed by planners.
Section 28.5 replaces discrete voxels with a continuous neural radiance field, gaining photorealistic novel-view synthesis at the cost of needing an explicit geometry extraction step before the map can answer collision queries.
Section References
Open3D. Voxel grid documentation. https://www.open3d.org/docs/release/tutorial/geometry/voxelization.html
Shows practical voxel representations and conversions.
NVIDIA. Isaac ROS Visual SLAM documentation. https://nvidia-isaac-ros.github.io/repositories_and_packages/isaac_ros_visual_slam/index.html
Visual odometry context for maps that feed navigation.
Can you name the representation, the consuming action, the uncertainty or freshness field, and the failure label for Occupancy grids and voxel maps? If any one is missing, the section is not yet ready for a robot replay log.
Occupancy grids are powerful because they answer the planner's simplest question: is this space free, occupied, or still unknown?
Design an unknown-space policy for a drone inspecting a warehouse aisle. When should unknown be allowed, penalized, or forbidden?
