Worked Example: Euler vs RK4 vs Symplectic Euler on a Pendulum
The cleanest stress test for an integrator is an undamped pendulum, because its true total energy is conserved exactly. Any energy the integrator gains or loses is pure numerical artifact. The pendulum equation of motion comes from the Lagrangian $L = T - V$ with $T = \tfrac{1}{2}m\ell^2\dot{\theta}^2$ and $V = -mg\ell\cos\theta$. Applying the Euler-Lagrange equation $\tfrac{d}{dt}\tfrac{\partial L}{\partial\dot{\theta}} - \tfrac{\partial L}{\partial\theta} = 0$ gives $\ddot{\theta} = -\tfrac{g}{\ell}\sin\theta$.
Three integrators handle the same dynamics very differently:
- Explicit (forward) Euler uses the old velocity for both updates. It systematically injects energy and the orbit spirals outward: it drifts.
- Symplectic (semi-implicit) Euler updates velocity first, then uses the new velocity to update position. It does not conserve energy exactly but the error stays bounded for all time, so it is energy-stable. This is why MuJoCo and most game physics engines use it.
- RK4 takes four stage evaluations per step. Its local truncation error is $O(\Delta t^5)$, so for smooth motion it is far more accurate, though over very long horizons it still slowly dissipates energy.
import numpy as np
g, L = 9.81, 1.0
def accel(theta):
return -(g / L) * np.sin(theta)
def energy(theta, omega):
return 0.5 * L**2 * omega**2 + g * L * (1 - np.cos(theta))
def integrate(method, theta0, omega0, dt, steps):
theta, omega = theta0, omega0
E = [energy(theta, omega)]
for _ in range(steps):
if method == "euler": # explicit Euler
theta_new = theta + dt * omega
omega_new = omega + dt * accel(theta)
theta, omega = theta_new, omega_new
elif method == "symplectic": # semi-implicit Euler
omega = omega + dt * accel(theta)
theta = theta + dt * omega
elif method == "rk4":
def f(s):
th, om = s
return np.array([om, accel(th)])
s = np.array([theta, omega])
k1 = f(s)
k2 = f(s + 0.5 * dt * k1)
k3 = f(s + 0.5 * dt * k2)
k4 = f(s + dt * k3)
s = s + (dt / 6.0) * (k1 + 2*k2 + 2*k3 + k4)
theta, omega = s
E.append(energy(theta, omega))
return np.array(E)
theta0, omega0 = 0.5, 0.0 # release from 0.5 rad at rest
dt, steps = 0.05, 4000 # 200 s of simulated time
E0 = energy(theta0, omega0)
for method in ["euler", "symplectic", "rk4"]:
E = integrate(method, theta0, omega0, dt, steps)
drift = (E[-1] - E0) / E0 * 100
print(f"{method:<11} energy drift over 200 s: {drift:+8.2f}% "
f"(min={E.min():.4f}, max={E.max():.4f})")
The printed drift makes the contrast concrete: explicit Euler gains a large positive percentage (the pendulum swings ever higher, which is physically impossible), symplectic Euler keeps the energy oscillating within a small bounded band around $E_0$, and RK4 holds energy to within a tiny fraction of a percent. The lesson for embodied AI: choose the integrator for the property the task needs. Use symplectic methods for long-horizon stability in a learning loop, and a high-order method like RK4 when short-horizon trajectory accuracy matters more than energy bookkeeping. Always log $\Delta t$ and the integrator, because the policy learns the discrete system you actually simulate, not the continuous one you intended.
For Numerical integration and stability, the hand-built fragment exposes the physical assumption before maintained tools take over. MuJoCo, MJX, Drake, Pinocchio, and Isaac Lab are useful only when the same mass, contact, actuator, and timestep contract is preserved.
Practical Recipe
- Write the observation, action, and success metric before choosing a model.
- Build a baseline that is simple enough to debug by inspection.
- Add the library implementation only after the baseline behavior is understood.
- Record failures as structured cases: perception error, state error, planning error, control error, or evaluation error.
- Run at least one perturbation test before trusting the result.
The common mistake in Numerical integration and stability is to celebrate the component score before checking the closed-loop handoff. The failure usually appears at the boundary: stale state, wrong frame, delayed action, saturated actuator, or metric that ignores the real task cost.
A robotics team using Numerical integration and stability should log not only final success, but intermediate observations, chosen actions, controller status, and recovery events. The logs reveal whether the method is solving the task or merely passing the easiest episodes.
Treat numerical integration and stability like a control-room label. If the label does not tell a future debugger what moved, what sensed, or what failed, it is decoration rather than engineering knowledge.
For Numerical integration and stability, treat frontier claims as hypotheses until they expose enough detail to reproduce the result: data boundary, embodiment, controller interface, evaluation panel, and failure cases.
Can you name the observation, state estimate, action, success metric, and most likely failure mode for Numerical integration and stability? If not, the system boundary is still too vague.
Production Pattern
Numerical integration and stability sits inside the Part II robotics contract: geometry defines where things are, kinematics defines what motion is possible, dynamics defines what motion costs, control defines how errors are corrected, and sensing defines what the agent can know on time.
Tie numerical integration choices to stability, energy behavior, timestep, and controller update rate. This makes the section useful to students, builders, and researchers at the same time: the idea has an intuitive role, a formal interface, a runnable check, and a failure mode that can be reproduced.
An integrator is the contract that turns continuous dynamics into a sequence of states. The danger is that the sequence can be numerically stable even when it is physically wrong, or physically plausible for one timestep and unstable for another. For robot learning, that means a policy can learn simulator artifacts such as extra damping, energy gain, or contact jitter.
Do not treat $\Delta t$ as a rendering detail. It changes the discrete system the policy experiences, the stiffness the solver can tolerate, and the delay between control updates. A simulator result without timestep and integrator settings is not reproducible evidence.
For Numerical integration and stability, dynamics adds causes of motion: forces, torques, inertia, contact impulses, and integration. Keep units, solver step, contact parameters, and energy behavior visible.
| Tool or Library | What It Handles | Verification Check |
|---|---|---|
| MuJoCo | runs articulated dynamics and contact simulation for robot learning experiments | Verify timestep, solver parameters, contact settings, and reset semantics. |
| MJX | runs articulated dynamics and contact simulation for robot learning experiments | Verify timestep, solver parameters, contact settings, and reset semantics. |
| Drake | models dynamical systems, multibody plants, optimization, and controllers | Verify scalar type, plant finalization, frame convention, and solver status. |
| Pinocchio | computes articulated-body kinematics, dynamics, and derivatives | Verify model frames, joint ordering, and derivative convention against the URDF. |
| Isaac Lab | scales robot-learning simulation with GPU workflows and sensor-rich scenes | Verify environment parity, reset distribution, and logged seeds before training. |
Use this recipe when turning Numerical integration and stability into code, a simulator experiment, or a robot diagnostic. The point is not to use every library. The point is to keep the hand-built baseline and the maintained-tool path comparable.
- Specify mass, inertia, actuator limits, contact model, timestep, and solver tolerance before running a rollout.
- Run one free-motion test and one contact test with logged energy, constraint violation, and penetration depth.
- Compare the hand calculation with MuJoCo, Drake, Pinocchio, or MJX on the same model and timestep.
- Store solver settings, random seed, initial state, trajectory, and failure labels in one artifact.
- Scale to Isaac Lab or GPU-parallel simulation only after a small model passes deterministic checks.
For Numerical integration and stability, compare methods only through one saved artifact that preserves the inputs, outputs, units, timestamps, latency budget, configuration, seed, metric definition, and failure labels relevant to this section. The comparison is meaningful only when the same script evaluates the same panel.
Extend the section exercise by adding one perturbation specific to Numerical integration and stability and one latency or uncertainty check. Save the result in the EvidenceRecord schema, then explain which library output you trust and why.
For Numerical integration and stability, distrust smooth simulation until the section-specific physical assumption has been stress-tested: timestep, contact stiffness, damping, friction, actuation, and energy behavior should each have a small diagnostic.
Technical Core
Numerical integration and stability needs a topic-native core: variables, equations or system contracts, an algorithmic procedure, an expected output, and a failure diagnosis. Figure 6.4.T summarizes the chain this section must preserve when moving from a teaching example to a real embodied system.
For $\dot x=f(x,u)$, explicit Euler uses $x_{k+1}=x_k+\Delta t f(x_k,u_k)$. Semi-implicit Euler first updates velocity, then uses the new velocity to update position, which often behaves better for mechanical energy. Runge-Kutta methods reduce local truncation error for smooth motion, while implicit methods trade a nonlinear solve for better behavior on stiff springs, damping, and contact constraints.
- Run the same initial state with $\Delta t$, $\Delta t/2$, and $\Delta t/4$, then compare trajectory, task metric, and energy drift.
- Test free motion separately from contact-rich motion so contact solver artifacts do not hide integrator errors.
- Record integrator type, internal solver iterations, control update rate, sensor update rate, and substep count.
- Reject a policy comparison when a win disappears under timestep refinement or depends on a different integrator setting.
| Contract Field | What To Specify | Why It Matters |
|---|---|---|
| State and observation | Variables, units, timestamps, frames, and uncertainty. | Prevents a model score from being mistaken for robot capability. |
| Action interface | Command type, limits, update rate, and safety fallback. | Makes the learned or planned output executable. |
| Evidence artifact | Trace, metric, configuration, seed, and failure label. | Allows baseline and library path to be compared in one pass. |
| Tool path | MuJoCo, Drake, Isaac Sim, Gazebo, PyBullet, SAPIEN, NumPy | Shows the practical library route after the mechanism is understood. |
For Numerical integration and stability, expected output is a state trace with the relevant physical invariant: bounded energy error for free motion, bounded penetration for contact, and a solver-status field that explains divergence.
Numerical integration and stability is validated by conserved quantities where they should hold, stable contact where contact is expected, and reproducible divergence under a named parameter perturbation.
