Section 4.5: 2D and 3D transformations; transform trees (tf in ROS)

A Careful Control Loop

This section develops the technical contract for 2D and 3D transforms as a graph problem. First we define a transform tree as a directed acyclic frame graph with one parent per child. Then we show how a lookup composes edges along a path. Finally we connect the math to the ROS tf2 discipline of stamped transforms, buffer windows, and explicit lookup times.

The key question is practical: when a camera detects an obstacle, which chain of transforms converts that obstacle into the planning frame at the time the planner needs it?

Theory

A transform tree stores edges such as $T_{\text{map},\text{odom}}$, $T_{\text{odom},\text{base}}$, and $T_{\text{base},\text{camera}}$. A lookup from camera to map follows the unique path through the tree and composes the transforms in path order:

$$T_{\text{map},\text{camera}} = T_{\text{map},\text{odom}}T_{\text{odom},\text{base}}T_{\text{base},\text{camera}}.$$

This is why tf2 insists on parent and child frame names. Without the names, a transform matrix is only a 4 by 4 array. With the names and timestamp, it becomes a claim about where one coordinate convention sits relative to another at a specific time.

2D transforms are the same idea with fewer degrees of freedom. A planar robot often uses $(x, y, \theta)$ and the group SE(2). A flying robot, manipulator, or camera-bearing humanoid needs SE(3), because roll, pitch, yaw, and vertical translation are load-bearing state variables.

Worked Example

Code Fragment 4.5.1 implements the smallest useful transform-tree lookup. It stores three edges, composes the path from map to camera, and applies the resulting transform to one point reported by the camera.

# Compose a tf-style path from map to camera and transform one point.
# Each edge is named by parent and child frame to prevent silent direction bugs.
# The example omits rotation so the path arithmetic is easy to inspect.
import numpy as np

def translate(x, y, z):
    transform = np.eye(4)
    transform[:3, 3] = [x, y, z]
    return transform

edges = {
    ("map", "odom"): translate(2.0, 0.0, 0.0),
    ("odom", "base_link"): translate(0.5, 1.0, 0.0),
    ("base_link", "camera"): translate(0.2, 0.0, 0.8),
}

path = [("map", "odom"), ("odom", "base_link"), ("base_link", "camera")]
map_from_camera = np.eye(4)
for edge in path:
    map_from_camera = map_from_camera @ edges[edge]

point_camera = np.array([1.0, 0.0, 0.0, 1.0])
point_map = map_from_camera @ point_camera
print(point_map[:3].round(3).tolist())

Expected output: the point moves by the sum of the three translations. If a real tf2 lookup gives a different direction, inspect whether the code requested source-to-target or target-to-source, and whether the lookup time matches the sensor timestamp.

Transform-tree bugs look like weak perception or control. Check parent-child direction, timestamp, static-vs-dynamic classification, and buffer latency before changing the robot policy.
